10-704-RM-PP — Hex Receptacle — 10-Pack
Hex-body wiring enclosure with clamp bracket and NPT conduit entry.
Hex-body wiring enclosure with clamp bracket and NPT conduit entry.
| Quantity | Price |
|---|---|
| 1–2 | $199.63 |
| 3–4 | $175.32 |
| 5–9 | $168.38 |
| 10–99 | $72.55 |
The 10-704-RM hex receptacle is a wiring enclosure with hex wrench flats, clamp bracket, and NPT conduit entry. Designed for secure pipe and tank mounting. Sold in 10-pack quantities.
| Specification | Value |
|---|---|
| Type | Hex receptacle with clamp bracket |
| Switch Positions | 1 switch + tube |
| Conduit | NPT entry |
| Max Temperature | PP: 180°F / AC: 200°F / KR: 280°F |
| Material | Polypropylene |
A float level switch like the 10-704-RM-PP is a point-level device: a float rides the liquid and actuates a magnetic reed switch at a set height, giving a simple on/off signal — no power, no firmware, no calibration. "Sensors" usually means continuous measurement (ultrasonic, radar, capacitive). ERECTA SWITCH targets reliable discrete-point control.
The 10-704-RM-PP is used for pump start/stop control, high-level overflow protection, low-level dry-run protection, and tank or reservoir level alarms in OEM equipment. The modular ERECTA SWITCH system is built into laundry, HVAC, water-treatment, hydraulic, and chemical-handling machinery.
Choose the material to match the media: Polypropylene (PP) for general aqueous, acids, and bases; Acetal (AC/Delrin) for solvents, fuels, and hydrocarbons; Kynar PVDF (KR) for aggressive or harsh chemicals. Every ERECTA SWITCH model is offered in all three materials.
The 10-704-RM-PP is point-level — it provides a discrete on/off signal at a set height. For multiple switch points, use a multi-level extended-stem set (2-, 3-, or 4-level) instead of a single continuous sensor.
ERECTA SWITCH offers vertical top-mount, bulkhead, and extended-stem configurations, plus side-mounted single-point models. The mount style is part of the model number — select the configuration that matches your tank geometry.
Point detection is repeatable and mechanical. The trip height on the 10-704-RM-PP is set by the 10-715 Precision Nipple, ordered separately in 1-inch increments (1″–70″), so you place the switch point exactly where the application needs it.
Our engineering team can verify compatibility with your application and chemistry before you order.
